제품 상세 정보:
결제 및 배송 조건:
|
| 제품: | 강철 산책로 격자 | 키워드: | 강철 격자판 |
|---|---|---|---|
| 표면 유형: | 톱니 모양입니다 | 특징: | 내구성이 있고 무겁고 슬립 |
| 재료: | 강철 | 인기있는 크기: | 30x3mm 32x5mm 40x5mm |
| 베어링 바 피치: | 15,20,25,30,33,35,38,40,50,60,80mm | 베어링 바: | 20x5, 25x3, 25x4, 25x5, 30x3, 30x5 |
| 설치 방법: | 용접 | 크로스 바 피치: | 40, 50, 60, 65, 76, 100 등 |
| 두께: | 1.5-8mm | 색상: | 은 |
| 강조하다: | serrated steel walkway grating,corrosion resistant grating panel,steel walkway grating panel |
||
| Type | Welded steel grating, pressure locked, socket welding |
|---|---|
| Material | Low carbon steel, stainless steel, aluminum |
| Bearing bar | 20x5, 25x3, 25x4, 25x5, 30x3, 30x4, 30x5, 32x3, 32x5, 40x5, 50...75x8mm, etc. |
| Bearing bar pitch (center to center) | 25, 30, 30.16, 32.5, 34.3, 40, 50, 60, 62, 65mm, etc. or according to client requirements |
| Cross bar | 5x5, 6x6, 8x8mm (twisted bar or round bar) |
| Cross bar pitch | 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm or as customers' requirement |
| Flat bar type | Plain, Serrated (tooth-like) |
| Material standard | Bearing bar | Cross bar | Bearing bar pitch | Cross bar pitch |
|---|---|---|---|---|
| Q235 | 25mm*3mm 25mm*5mm 30mm*3mm |
5mm 6mm |
20mm 22mm 27mm |
50mm 30mm |
| Q345 | 30mm*5mm 32mm*3mm 32mm*5mm |
6mm | 30mm | 100mm |
| ASTM A36 | 35mm*5mm 40mm*3mm 40mm*5mm |
8mm | 31mm 32mm 34mm |
100mm |
| ss400 | 75mm*5mm 75mm*8mm |
8mm | 40mm | 100mm |
