| 제품 이름: | 금속 폴 링 / 랜덤 포장 | 핵심 단어: | 무작위 포장 |
|---|---|---|---|
| 재료: | 스테인레스 강 304 / 316 | 크기: | 16,25,38,50,76mm 또는 맞춤형 |
| 공허분율: | 높은 | OEM: | 예 |
| 성능: | 열 내성 | 압력 강하: | 낮은 |
| 특징: | 저압 강하, 고효율 | 로딩 포트: | Xingang 포트 |
| 강조하다: | Stainless Steel 316 Pall Rings,Metal random packing for gas scrubbing,316 stainless steel Pall Ring packing |
||
| Attribute | Value |
|---|---|
| Product Name | Metal Pall Ring / Random Packing |
| Material | Stainless Steel 304 / 316 |
| Size | 16,25,38,50,76mm or Customized |
| Void Fraction | High |
| Performance | Heat-resistant |
| Pressure Drop | Low |
| Feature | Low Pressure Drop, High Efficiency |
| Port Of Loading | Xingang Port |
The Metal Pall Ring is a highly efficient packing material designed for vacuum distillation processes, offering optimal surface area and void space for superior heat transfer. This versatile packing solution is also ideal for various industrial applications including gas absorption, cooling systems, and air purification.
| Size (inch/mm) | Bulk Density (SS304 kg/m3) | Number (per m3) | Surface Area (m2/m3) | Free Volume (%) | Dry packing factor m-1 |
|---|---|---|---|---|---|
| 1" (25×25×0.4) | 288 | 53500 | 212 | 96.2 | 229.8 |
| 1" (25×25×0.5) | 367 | 53500 | 216 | 95 | 237.2 |
| 1" (25×25×0.6) | 439 | 53500 | 219 | 94.2 | 244.1 |
| 1.5" (38×38×0.4) | 193 | 15180 | 143 | 97.2 | 148.4 |
| 1.5" (38×38×0.5) | 246 | 15180 | 145 | 96.7 | 151.7 |
| 1.5" (38×38×0.6) | 328 | 15000 | 146 | 95.9 | 154.6 |
| 2" (50×50×0.5) | 185 | 6500 | 106 | 97.5 | 128.5 |
| 2" (50×50×0.7) | 315 | 6500 | 108 | 96.4 | 130.5 |
| 2" (50×50×0.9) | 380 | 6500 | 132.5 | 95.4 | 134.0 |
| 3" (76×76×0.8) | 265 | 1920 | 69 | 97.4 | 79.6 |
