Stainless Steel 316L Metal Random Packing for High Efficiency Towers

Stainless Steel 316L Metal Random Packing for High Efficiency Towers

큰 이미지 :  Stainless Steel 316L Metal Random Packing for High Efficiency Towers

제품 상세 정보:
브랜드 이름: Yuanhai
인증: ISO9001:2015
Model Number: YH-04
결제 및 배송 조건:
Minimum Order Quantity: 1 M³
가격: $120-1500 / m³
Packaging Details: By Wooden Box
Delivery Time: 7 Days
Payment Terms: T/T
Supply Ability: 800 Cubic Meter/Cubic Meters Per Month
상세 제품 설명
제품 이름: 금속 무작위 포장 핵심 단어: 타워 포장 /랜덤 포장
재료: 스테인레스 강 304 / 316 로딩 포트: Xingang 포트
크기: 사용자 정의 HS 코드: 8419909000
특징: 저압 강하, 고효율 성능: 열 내성
OEM: 인증: ISO9001:2015
강조하다:

Stainless Steel 316L random packing

,

high efficiency metal packing

,

metal tower packing with warranty

SS316L Metal Random Packing for High Efficiency Tower Packing
Product Specifications
Attribute Value
Product Name Metal Random Packing
Material Stainless Steel 304 / 316
Port Of Loading Xingang Port
Size Customized
Feature Low Pressure Drop, High Efficiency
Performance Heat-resistant
Certification ISO9001:2015
Product Description
SS316L High Void Fraction Metal Random Packing (50×50×1.0mm) is manufactured from durable materials including stainless steel 304/316. This tower packing solution features thin walls, heat resistance, high free volume, and superior separation efficiency, making it ideal for vacuum rectification towers handling sensitive materials.
Key Features
  • High Mechanical Strength: Perforated walls reduce weight while maintaining structural integrity
  • Optimized Flow Characteristics: Low pressure drop design reduces energy consumption
  • Enhanced Mass Transfer: Unique tongue structures maximize gas-liquid contact area
  • Superior Fouling Resistance: Open structure prevents clogging while maintaining efficiency
  • Wide Temperature Range: Suitable for both low and high temperature applications
Technical Parameters
Size (mm) Bulk Density (kg/m³) Quantity (per m³) Surface Area (m²/m³) Free Volume (%)
16×16×0.3 360 201,000 346 95.5
25×25×0.4 302 51,000 212 96.2
38×38×0.5 262 15,180 145 96.7
50×50×0.8 315 6,500 108 96.4
76×76×0.8 205 1,830 69 97.4
Applications
  • Absorption and scrubbing systems (CO₂/H₂S removal, air pollution control)
  • Heat transfer processes
  • Liquid-liquid extraction columns
  • Light ends fractionators in petrochemical applications
Frequently Asked Questions
Brand: Yuanhai (Model: YH-04)
Manufacturing Location: Hebei Province, China
Certification: ISO9001:2015 certified
Minimum Order: 1 m³
